NRD-04 v2.4.1 firmware released · API v3.2 backward compatible · Apr 28 1,247 units deployed · 24 countries · uptime 99.94%
LIVE · MFG. STOCKHOLM ★ NEW · NRD-04 EST. 2018 · 32 PEOPLE ISO 9001 · IEC 61010-1

Rugged air-quality monitors, built for industry. The NRD-04 is our fourth-generation industrial air-quality monitor — PM1, PM2.5, PM10, CO₂, CO, NO₂, VOC, temp, RH, and pressure on a single board, with two-year battery life and direct LoRaWAN backhaul. Installed in 1,247 industrial facilities across twenty-four countries since November 2024.

— Models in production

5

— Units deployed

1,247

— Countries

24

— Uptime · '24

99.94%

§ 01 · LINEUP

Five models in production

Updated Apr 2025
v2.4.1 firmware

— SPEC ↓ · MODEL →
NRD-01
NRD-02
NRD-03
★ NRD-04
NRD-04-X
Class
Indoor · light
Indoor · industrial
Outdoor · IP66
Outdoor · IP69K · hazardous
Code
N-01.A2
N-02.A4
N-03.B2
N-04.X1
Sensors
PM2.5 · PM10 · CO₂ · temp · RH
+ CO · VOC
+ NO₂ · pressure
+ H₂S · CH₄ · ATEX cert.
Backhaul
Wi-Fi · BLE
Wi-Fi · BLE · Ethernet
Wi-Fi · LoRaWAN · 4G
LoRaWAN · 4G · sat-IoT
Power
USB-C / mains
PoE / mains
Solar + 18650 / mains
Solar + 18650 (×4) / mains · 4 yr
Op. range
0 — 50°C · indoor
−10 — 60°C · indoor
−25 — 65°C
−40 — 85°C · hazardous
Sample rate
10 min
5 min
1 — 5 min
10 s — 5 min
Certifications
CE · FCC · UKCA
CE · FCC · UKCA · RoHS
+ IEC 61010-1
+ ATEX zone 1 · IECEx 1
Warranty
2 yr
3 yr
5 yr
7 yr · + unlimited firmware
Unit price
€340
€620
€1,180
€2,940 · qty break ≥ 25u

§ 02 · INSTALLATION

Dimensions & mounting

All NORDEN units share a common 142 × 102 × 48mm enclosure, mounted via DIN-rail clip or M6 wall bracket. The unit is field-serviceable; the sensor module pops out from the front via two M3 captive screws. Mean time between sensor replacement: roughly 4 years for PM, 6 years for gas.

⟵ 142.0 mm ⟶
↕ 102.0 mm
depth 48.0 mm — full IP67
— EXT DIMENSIONS142 × 102 × 48 mm · WxHxD
— ENCLOSURECast Al alloy powder-coated, RAL 9005
— WEIGHT740 g ± 12g · per QC
— MOUNT TYPESDIN-rail / M6 bracket both supplied
— IP RATINGIP67 dust-tight, 30 min @ 1m submersion
— PORTM12 × 4-pin power · ethernet · field bus
— DISPLAY2.13" E-paper persistent, 0 W between updates
— SENSOR ACCESSFront · M3 captive field-serviceable, no tools
— CABLE GLANDM16 × 1.5 cable Ø 4 — 8mm
— LIFECYCLE10+ yrs MTBF 110,000 hrs @ 25°C

§ 03 · DEPLOYED

In the field · selected deployments.

1,247— Units deployed
24— Countries
99.94%— Uptime '24
IDFACILITYLOCATIONCONFIGUNITSSINCE
D-014
SSAB Oxelösund Steel Worksintegrated steel · scope 1 air monitoring
Sweden, EU NRD-04 · LoRaWAN · solar 142 units 2022 Q3
D-038
Refinería Acapulcopetrochemical · ATEX zone 1 perimeter
Mexico NRD-04-X · sat-IoT · solar 68 units 2023 Q4
D-051
Port of Rotterdam — APMT Maasvlakte IIcontainer terminal · diesel-exhaust monitoring
Netherlands, EU NRD-04 · LoRaWAN · mains 94 units 2024 Q1
D-067
Wabtec Erie Locomotive Workslocomotive manufacturing · indoor + perimeter
Pennsylvania, US NRD-03 + NRD-04 mix · 4G 112 units 2024 Q2
D-082
Tata Steel Port Talbotintegrated steel · phased UK rollout · ongoing
Wales, UK NRD-04 · LoRaWAN · 4G fallback 86 units · ongoing 2024 Q4
D-094
Northvolt Ett Skellefteåbattery gigafactory · indoor only · LFP/NMC lines
Sweden, EU NRD-02 · PoE · mains 204 units 2023 Q1
D-118
YPF Mendoza Refinerypetrochemical · ATEX zone 0/1/2 perimeter
Argentina NRD-04-X · sat-IoT · solar (×4) 48 units 2025 Q1

— 1,240 more deployments. Customers under NDA include 6 of the 10 largest European steel producers. Reference list (under NDA) →

§ 04 · COMPANY

Built in Stockholm, since 2018.

— FoundedMMXVIII
— Headcount32
— Engineers22
— Funding raised€18M
— ManufacturingIn-house
— Revenue '24€14.2M
— Gross margin '2452%
— Customer retention98% 5yr

NORDEN was founded in November 2018 by Dr. Annika Lindqvist (formerly of the Royal Institute of Technology) and Henrik Ljungberg (formerly of ABB Industrial Automation), after eight years of work together on industrial air-quality instrumentation. The company's first office was the basement of Annika's grandfather's machine shop in Bromma, and the first units of the NRD-01 were assembled, by hand, on a four-station workbench Henrik had built the prior winter.

Seven years later, we are thirty-two people — twenty-two of them engineers — and we manufacture the NORDEN line in a leased facility on the south end of Stockholm. We are not large. We do not aspire to be large. We have, on purpose, kept the company small enough that every product we ship is reviewed in person by either Annika or Henrik before it leaves the factory.

What we build is industrial-grade environmental instrumentation for facilities — steel mills, petrochemical refineries, container ports, locomotive works, battery gigafactories — that need to know, continuously and reliably, what is in the air around their operations. Our customers do not want a smart thermostat. They want a rugged measurement device that will last ten years on a pole in the rain at -30°C, and report through a 12.8 km LoRaWAN link to a system they already own.

We sell direct, in batches of fifty units or more, with standard 5-year warranty and unlimited firmware support. We do not sell through Amazon, distributors, or resellers. For evaluation units in quantities of one to four, please contact our engineering team directly via the form below — we will respond within one business day. Most engineering evaluations turn into a deployment within sixty days.

§ 05 · REQUEST EVAL

Request an engineering evaluation.

For volumes of fifty units or more, we typically ship a free 4-unit evaluation kit within three working days. Includes one NRD-04, two NRD-02 indoor units, one NRD-04-X for hazardous-area testing, all cloud-connected for 90 days, and an engineering call to review your specific deployment constraints. No purchasing commitment.
